5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

Shenzhen Nomo Electronics Co., Ltd.
Contact Now

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

Brand Name : NOMO

Model Number : HP-4000

Certification : IP65, CE, ROSH, ISO9000

Place of Origin : CHINA

MOQ : 10PCS

Price : Negotiation

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : IN STOCK

Delivery Time : IN STOCK

Packaging Details : NEUTRAL PACKING

Dimension of product : 1295*350*80mm

Wind load rate : 35m/s

Lumen output : 5000LM

Contact Now

The Integrated design combined with the latest in lighting technology makes HYPERION SERIES LED solar street lights a class leader when it comes to protecting your immediate environment.

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

FEATURES:

1. Easy to install:

It doesn’t require an electrical grid, digging or experience with electricity. All you need to do is to put the light in a sunny spot, let it charge and enjoy.

2. Require no maintenance:

You won’t have to worry about maintenance with using Hyperion Integrated LED Solar Street Light. All they need is to make sure the solar panel on each light working at its best.

3. Cost nothing to operate:

Hyperion series integrated LED Solar Street Light cost nothing, absolutely ZERO, because they run entirely on the sunlight.

4. Integrated design:

LED solar fixtures can be used as area lights, street lights, wall lights, driveway lights, parking lot lights, security night lights, patio lights, flood lights or yard lights.

PARAMETER:

MODEL HP- 5000LM
PARAMETERS
PV Module 90W
Life Time 25 Years (The power attenuation of each year is around 1%)
LED Luminous 5000LM
LED Chip 5050 LED
Viewing Angle 70°*140°
Color Temperature 3000K-6500K,Typical(5500K-6000K)
Color Rendering Index >70
Life Time >5 Years
Battery Tape LiFePo4 Battery
Battery Capacity 346WH
Battery Life Time (5-8 Years)
MPPT Charge Controller Including wireless communication module
(Please see the Communication topology below)
Timing Mode 1Hr 50% ,4Hrs 100%,3Hrs 50%,4Hrs 25%.
Infrared induction is optional
Circuit Protection Overcharge, discharge, short circuit, open load, lightning protection and other functions
Life Time 5-8 Years
Charging Time (STC) 6-8 Hrs (Under STC)
Certificate CE, ROSH, IP65, ISO9000, IEC TEST REPORT
Working Temperature -20℃~+60℃ (When the temperature is below -10℃, derating use)
Storage Temperature 0℃~45℃
Protection Grade IP67
Dimension Size(mm) 905*350*80mm
Installation Height 4 m to 6m light pole
Installation Diameter <80mm
Installation Distance 15m to20m

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

WORKING MODE:

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

ADAPTIVE ROAD TYPE SIMULATION

Height:10m; width:7m; Pole distance; 30m;lighting arrange on one side ,simulated data

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

5000lm Led Outdoor Area Street Lighting Alluminum Alloy Body With Good Heat Dissipation

5000lm Outdoor Integrated LED Solar Street lamp with good heat dissipation , whole alluminum alloy body
